BMP61 M611 Thermoplastic Polyether Polyurethane Tags

Availability: In Stock

₦69,967.80
Hurry up! only 2 products left in stock!
BMP61 M611 Thermoplastic Polyether Polyurethane Tags Product Highlights Dimensions: 15,00 mm (W) x 75,00 mm (H) Colour: Yellow Brady Material Type: Thermoplastic Polyether Polyurethane Brady Material No.: Overview These B-7643 cable tags contain no added...
Request for Quote
Quntity:
Buy Now

Product code:

M61-15X75-7643-YL

BMP61 M611 Thermoplastic Polyether Polyurethane Tags

Product Highlights

Dimensions:

15,00 mm (W) x 75,00 mm (H)

Colour:

Yellow

Brady Material Type:

Thermoplastic Polyether Polyurethane

Brady Material No.:


Overview

These B-7643 cable tags contain no added halogens and offer excellent fire safety characteristics combined with minimal smoke emission.



Specifications

Key Characteristics Article Number 303349
Order Reference M61-15x75-7643-YL
Total Qty per Pack 50 Tag(s) / Roll
QTY. per Row 1
Application(s)  Data and telecommunications labelling, Wire and cable labelling
Quantity 50
Voice/Data Application Communication Cables
Brand Brady®
Qty per Roll 50
Ribbon Series R6000HF
Country of Origin  BE
Dimensions Size - Width (mm) 15.00 mm
Size - Height (mm) 75.00 mm
Hole Diameter (mm) 5.00 x 2.00 mm
Printable Area Dimensions 15,00 mm W x 55,00 mm H
Printable Area - Height (mm) 55.00 mm
Printable Area - Width (mm) 15.00 mm
Vertical Repeat (mm) 80.43 mm
Web Width (mm) 39.67 mm
Dimensions 15,00 mm (W) x 75,00 mm (H)
Material Characteristics Brady Material No.
Brady Material Type Thermoplastic Polyether Polyurethane
Material Properties Zero-halogen
Thickness (mm) 0.45 mm
Colour Yellow
Max. Service Temp. °C 90 °C
Min. Service Temp. °C -40 °C
Finish Matt
Resistance Properties Abrasion-resistant, Chemical-resistant, Humidity-resistant
Product Features # of Holes 4
Shape Rectangle
Hole Shape Oval
Printing Specifications Print Technology Thermal Transfer
Max. Characters per Line 51
Smart Cell Yes
Compatibility Printer Compatibility BMP61, BMP71, M611
Compliance UNSPSC  55121503
RoHS Compliance Status Compliant with Directive 2011/65/EU and 2015/863
REACH SVHC Status Part does not contain an SVHC
REACH Candidate List Date 16 July 2019
Approval/Compliance Halogen free per IEC 61249-2-21 (2003-11), Adherence: SAE-AS81531-1998, Flame retardant: MIL-STD-202G

Application(s):

Data and telecommunications labelling, Wire and cable labelling

Finish:

Matt

Printer Compatibility:

BMP61, BMP71, M611
